1/1

HUSQVARNA 525RX

Cylinder displacement

1.55 cu.inch

Power output

1.34 hp

Product Options

What's Included

HUSQVARNA 525RX - 967 17 57‑01

Included

Grass blade
Grass 255-4
Harness
Balance 35
Trimmer head
T35 M10

Product Description

Blaze a trail with a superior brushcutter. The Husqvarna 525RX is a powerful yet lightweight and comfortable brushcutter that leads the industry in more ways than one. Featuring pro-grade components and our world-renowned X-Torq® engine, the 525RX is tough on grass and undergrowth, but easy on you. Comes with an ergonomic harness to keep you balanced, safe and efficient throughout the day.

Product Information

Features(12)

Intuitive controls
Easy to use and maneuver
View more
X-Torq® engine
X-Torq® engine cuts emission and fuel consumption
View more
Offset handle bar
Offset handle bar for best comfort
View more
Balance 35
Balance 35 ergonomic harness
View more
Quick Start with Air Purge
Air purge for easier cold starting
View more
High Line Capacity
Tap 'n' Go trimmer head is easy to use and refill
View more
Auto return stop switch
Auto return stop switch for easy starting
View more
Versatile guard
Versatile use with combi guard
View more
High offset post
High hande bar, more leg space
View more
Stand alone starter
Easy to service and maintain starter
View more
Optimal Cutting Performance
Trimmer head designed for high torque to deliver optimal cutting performance when parallel to the ground
View more
Adjustable handle bar
Adjustable handle bar for best comfort
View more

Specifications

525RX Art no: 967 17 57‑01
Engine	525RX Art no: 967 17 57‑01	525RX Art no: 967 17 57‑02
Torque, max.	1.2 Nm	1.2 Nm
Torque, max. at rpm	6,000 rpm	6,000 rpm
Cylinder displacement	1.55 cu.inch	1.55 cu.inch
Power output	1.34 hp	1.34 hp
Maximum power speed	8,500 rpm	8,500 rpm
Fuel tank volume	17.25 fl oz	17.25 fl oz
Fuel consumption	600 g/kWh	600 g/kWh
Idling speed	3,000 rpm	3,000 rpm
Electrode gap	0.03 in	0.03 in
Clutch engagement speed (±120)	4,000 rpm	4,000 rpm
Maximum rpm output shaft	6,500 rpm	6,500 rpm
Transmission
Gear ratio	19	19
Drive gear angle	30 °	30 °
Dimensions
Weight (excl. cutting equipment)	10.8 lbs	10.8 lbs
Tube length	58.386 in	58.386 in
Tube diameter	0.94 in	0.94 in
Equipment
Grass blade	Grass 255-4	Grass 255-4
Harness	Balance 35	Balance 35
Trimmer head	T35 M10	T35 M10
Lubricant
Lubricant type (Engine)	Husqvarna 2 stroke or equiv. at 50:1	Husqvarna 2 stroke or equiv. at 50:1
Sound and Noise
Sound power level, guaranteed (LWA)	106 dB(A)	106 dB(A)
Sound power level, measured	104 dB(A)	104 dB(A)
Sound pressure level at operators ear	93 dB(A)	93 dB(A)
Emission
Exhaust emissions (HC average)		32.47 g/kWh
Exhaust emissions (HC average)		32.47 g/kWh
Exhaust emissions (CO average)	87.57 g/kWh	87.57 g/kWh
Exhaust emissions (CO average)		254.3 g/kWh
Exhaust emissions (CO average)		254.3 g/kWh
Exhaust emissions (NOx average)	0.56 g/kWh	0.56 g/kWh
Exhaust emissions (NOx average)		0.2 g/kWh
Exhaust emissions (NOx average)		0.2 g/kWh
Vibration
Equivalent vibration level (ahv, eq) front handle	2.1 m/s²	2.1 m/s²
Equivalent vibration level (ahv, eq) rear handle	2.3 m/s²	2.3 m/s²
