Grass Trimmers
Parts, manuals and support for 525LST
All the support you need for 525LST. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 525LST product pageChoose your SKU
For more product support please choose your SKU below.
Spare parts
Choose the part you wish to repair
SHAFT AND HANDLE
Name
Price
Shop
Support content
Manuals & Documents
(11)
Manuals & Documents
(11)
Showing the latest version of manual and documents for 525LST. For earlier versions, see link below to search all manuals & documents..
Operator's Manual
Published: 4/17/20252.8 MB,EN, ESIllustrated Part List
Published: 2/14/202222.9 kB,EN
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | 25.4 cc, Straight Shaft Trimmer SKU: 967 17 55‑01 |
|---|---|
Output shaft power | 1.34 hp |
Cylinder displacement | 1.55 cu.inch |
Maximum rpm output shaft | 5,500 rpm |
Fuel tank volume | 17.25 fl oz |
Fuel tank volume | 0.51 l |
| Capacity | 25.4 cc, Straight Shaft Trimmer SKU: 967 17 55‑01 |
|---|---|
Cutting width | 18.1 in |
| Dimensions | 25.4 cc, Straight Shaft Trimmer SKU: 967 17 55‑01 |
|---|---|
Weight (excl. cutting equipment) | 10.36 lbs |
Tube diameter | 0.94 in |
Product size length | 70.43 in |
| Equipment | 25.4 cc, Straight Shaft Trimmer SKU: 967 17 55‑01 |
|---|---|
Gear ratio | 23 |
Drive gear angle | 30 ° |
Harness | Not included |
Saw blade | Not included |
Grass blade | Not included |
| Emission | 25.4 cc, Straight Shaft Trimmer SKU: 967 17 55‑01 |
|---|---|
Exhaust emissions (CO₂ EU V) | 1,141 g/kWh |
| Sound and noise | 25.4 cc, Straight Shaft Trimmer SKU: 967 17 55‑01 |
|---|---|
Sound power level, guaranteed (LWA) | 114 dB(A) |
Sound pressure level at operators ear (LpA) | 98 dB(A) |
