Grass Trimmers
Parts, manuals and support for 130L
All the support you need for 130L. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 130L product pageChoose your SKU
For more product support please choose your SKU below.
Spare parts
Choose the part you wish to repair
CLUTCH
Name
Price
Shop
Support content
Manuals & Documents
(2)
Manuals & Documents
(2)
Showing the latest version of manual and documents for 130L. For earlier versions, see link below to search all manuals & documents..
Operator's Manual
Published: 8/18/20252.57 MB,EN, ES, FRIllustrated Part List
Published: 11/27/2024570 kB,EN
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | 130L TRIMMER 28cc straight shaft FA, single pack SKU: 970 51 44‑02 |
|---|---|
Output shaft power | 1 hp |
Cylinder displacement | 1.7 cu.inch |
Maximum rpm output shaft | 7,184 rpm |
Fuel tank volume | 17.82 fl oz (US) |
Fuel tank volume | 0.53 l |
| Capacity | 130L TRIMMER 28cc straight shaft FA, single pack SKU: 970 51 44‑02 |
|---|---|
Cutting width | 18 in |
| Dimensions | 130L TRIMMER 28cc straight shaft FA, single pack SKU: 970 51 44‑02 |
|---|---|
Weight (excl. cutting equipment) | 12.2 lbs |
Tube diameter | 0.945 in |
Product size length | 70 in |
| Equipment | 130L TRIMMER 28cc straight shaft FA, single pack SKU: 970 51 44‑02 |
|---|---|
Gear ratio | 0.684 |
Drive gear angle | 60 ° |
Harness | Not included |
Saw blade | Not included |
Trimmer head | Not included |
Grass blade | Not included |
| Vibration | 130L TRIMMER 28cc straight shaft FA, single pack SKU: 970 51 44‑02 |
|---|---|
Equivalent vibration level (ahv, eq) front handle | 5.66 m/s² |
Equivalent vibration level (ahv, eq) rear handle | 8.93 m/s² |
| Sound and noise | 130L TRIMMER 28cc straight shaft FA, single pack SKU: 970 51 44‑02 |
|---|---|
Sound power level, guaranteed (LWA) | 116 dB(A) |
Sound pressure level at operators ear (LpA) | 95.4 dB(A) |
