Robotic Lawn Mowers
Parts, manuals and support for Automower® 435 iQ AWD
All the support you need for Automower® 435 iQ AWD. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to Automower® 435 iQ AWD product pageChoose your SKU
For more product support please choose your SKU below.
Spare parts
Choose the part you wish to repair
BLADE MOTOR AND CUTTING EQUIPMENT
Name
Price
Shop
Support content
Manuals & Documents
(4)
Manuals & Documents
(4)
Showing the latest version of manual and documents for Automower® 435 iQ AWD. For earlier versions, see link below to search all manuals & documents..
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
AM435iQAWD US, CA 970 74 52‑05 | |
|---|---|
Cutting System | |
Cutting system | 3 pivoting razor blades |
Cutting width | 8.7 in |
Skid plate | Yes |
Dual cutting direction | Yes |
AM435iQAWD US, CA 970 74 52‑05 | |
|---|---|
Capacity | |
Lawn Size (±20%) | 1.3 acre |
Maximum slope performance at boundary | 50 % |
Maximum slope performance inside installation | 70 % |
Max active time | 24 h |
Follow guide | Virtual transport path |
AM435iQAWD US, CA 970 74 52‑05 | |
|---|---|
Control | |
User Interface | Jogwheel, display and status LED:s/App |
Display | Color Display TFT 2,8” QVGA |
Smart Home integration | Yes |
Firmware Update | FOTA |
AM435iQAWD US, CA 970 74 52‑05 | |
|---|---|
Product data | |
Sound level perceived | 60 dB(A) |
Protection Index (IP Code) | IPX4 |
Typical mow time on one charge | 145 min |
AM435iQAWD US, CA 970 74 52‑05 | |
|---|---|
Overall dimensions | |
Weight | 39.9 lbs |
Product size width | 21.7 in |
Product size height | 13.1 in |
AM435iQAWD US, CA 970 74 52‑05 | |
|---|---|
Safety | |
GPS Theft tracking | Yes |
PIN code | Yes |
Lift sensor | Yes |
Tilt sensor | Yes |
AM435iQAWD US, CA 970 74 52‑05 | |
|---|---|
Dimensions | |
Product size length | 36.6 in |
Didn't find what you were looking for?
Use our Product Assistant to find support for your Husqvarna products easily. If needed, you are welcome to contact us for further assistance.
