Leaf Blowers
Parts, manuals and support for 570BFS
All the support you need for 570BFS. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 570BFS product pageChoose your SKU
For more product support please choose your SKU below.
Spare parts
Choose the part you wish to repair
HARNESS
Name
Price
Shop
Support content
Manuals & Documents
(4)
Manuals & Documents
(4)
Showing the latest version of manual and documents for 570BFS. For earlier versions, see link below to search all manuals & documents..
Operator's Manual
Published: 2/26/20253.91 MB,EN, ES, FRIllustrated Part List
Published: 9/13/2024806 kB,EN
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | 65.6cc, Backpack Blower, Frame Mount SKU: 966 62 95‑01 |
|---|---|
Cylinder displacement | 4 cu.inch |
Output shaft power | 4 hp |
Fuel tank volume | 74.4 fl oz |
Fuel Consumption | 431 g/kWh |
Maximum power speed | 8,000 rpm |
Idling speed | 2,000 rpm |
| Dimensions | 65.6cc, Backpack Blower, Frame Mount SKU: 966 62 95‑01 |
|---|---|
Weight | 24.47 lbs |
| Capacity | 65.6cc, Backpack Blower, Frame Mount SKU: 966 62 95‑01 |
|---|---|
Air flow in housing | 972 cfm |
Air flow in pipe | 768 cfm |
Air speed (flat nozzle) | 202 mph |
Air speed (round nozzle) | 236 mph |
Max Blow force | 37 N |
Air speed | 237.12 mph |
| Sound and noise | 65.6cc, Backpack Blower, Frame Mount SKU: 966 62 95‑01 |
|---|---|
Sound pressure level at operators ear (LpA) | 103 dB(A) |
Sound power level, guaranteed (LWA) | 110 dB(A) |
| Equipment | 65.6cc, Backpack Blower, Frame Mount SKU: 966 62 95‑01 |
|---|---|
Nozzle type | Round+ Flat |
Harness | Integrated |
Vacuum Kit | No |
| Vibration | 65.6cc, Backpack Blower, Frame Mount SKU: 966 62 95‑01 |
|---|---|
Equivalent vibration level (ahv, eq) handle | 5 m/s² |
