Leaf Blowers
Parts, manuals and support for 560BTS
All the support you need for 560BTS. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 560BTS product pageChoose your SKU
For more product support please choose your SKU below.
Spare parts
Choose the part you wish to repair
THROTTLE CONTROLS
Name
Price
Shop
Support content
Manuals & Documents
(2)
Manuals & Documents
(2)
Showing the latest version of manual and documents for 560BTS. For earlier versions, see link below to search all manuals & documents..
Operator's Manual
Published: 2/26/20253.91 MB,EN, ES, FRIllustrated Part List
Published: 2/15/202237.3 kB,EN
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
65.6cc, Backpack Blower 966 63 11‑02 | |
|---|---|
Engine | |
Cylinder displacement | 4 cu.inch |
Output shaft power | 3.81 hp |
Fuel tank volume | 74.4 fl oz |
Fuel Consumption | 422 g/kWh |
Maximum power speed | 8,100 rpm |
Idling speed | 2,000 rpm |
65.6cc, Backpack Blower 966 63 11‑02 | |
|---|---|
Dimensions | |
Weight | 23.15 lbs |
65.6cc, Backpack Blower 966 63 11‑02 | |
|---|---|
Capacity | |
Air flow in housing | 890 cfm |
Air flow in pipe | 631 cfm |
Air speed (round nozzle) | 232.42 mph |
Max Blow force | 30 N |
Air speed | 232 mph |
65.6cc, Backpack Blower 966 63 11‑02 | |
|---|---|
Sound and noise | |
Sound pressure level at operators ear (LpA) | 97 dB(A) |
Sound power level, guaranteed (LWA) | 111 dB(A) |
65.6cc, Backpack Blower 966 63 11‑02 | |
|---|---|
Equipment | |
Nozzle type | Round |
Harness | Integrated |
Vacuum Kit | No |
65.6cc, Backpack Blower 966 63 11‑02 | |
|---|---|
Vibration | |
Equivalent vibration level (ahv, eq) handle | 2.48 m/s² |
