Specifications
Specifications
| Engine | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Cylinder displacement | 53.3 cm³ |
Output shaft power | 2.8 kW |
Fuel tank volume | 1.1 l |
Fuel Consumption | 480 g/kWh |
Maximum power speed | 9,000 rpm |
Idling speed | 2,800 rpm |
Maximum rpm output shaft | 10,500 rpm |
Electrode gap | 0.5 mm |
Clutch engagement speed (±120) | 4,100 rpm |
Torque, max. | 3.5 Nm |
Torque, max. at rpm | 6,900 rpm |
Spark Plug | NGK BPMR7A |
| Capacity | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Cutting width | 54 cm |
| Equipment | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Grass blade | Shredder blade |
Harness | Balance XT2 |
Saw blade | Not included |
Trimmer head | Not included |
Handle type | Bullhorn |
| Dimensions | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Tube diameter | 35 mm |
Weight (excl. cutting equipment) | 9.2 kg |
Tube length | 1,483 mm |
| Lubricant | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Lubricant type (bevel gear) | Mineral grease |
| Emission | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Exhaust emissions (CO₂ EU V) | 1,000 g/kWh |
Exhaust emissions (HC average) EU | 52.86 g/kWh |
Exhaust emissions (CO average) EU | 239.74 g/kWh |
Exhaust emissions (CO average) EPA | 278.42 g/kWh |
Exhaust emissions (NOx average) EU | 1.72 g/kWh |
Exhaust emissions (NOx average) EPA | 1.69 g/kWh |
| Transmission | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Gear ratio | 1.47 |
Drive gear angle | 35 ° |
| Vibration | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Equivalent vibration level (ahv, eq) left handle | 2 m/s² |
Equivalent vibration level (ahv, eq) right handle | 1.5 m/s² |
| Sound and noise | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Sound pressure level at operators ear (LpA) | 103 dB(A) |
Sound power level, guaranteed (LWA) | 121 dB(A) |
| Control | Shredder blade, All ex US 50, CAN ,AUS, NZ Art no: 966 62 93‑02 |
|---|---|
Connectivity | Not applicable |
