1/8
Product variant
Bar length
Bar length (inch)
62.4 cm³
Cylinder displacement
5.4 hp
Power output1
69.9 fts
Chain speed at max power
What's included
What's included
Husqvarna 564 XP® Fuel Injected - 970 71 15‑02
Included
- Nose typeReplaceable sprocket nose
- SpikesMounted
- Chain typeC85
- Bar length (inch)18 in
Fuel injected 60cc professional chainsaw with instant acceleration
Husqvarna 564 XP is a groundbreaking 60cc chainsaw for forestry and tree care professionals seeking cutting-edge performance. Combining the size and maneuverability of a 50cc chainsaw with the power of a 70cc, it delivers an outstanding power-to-weight ratio in a compact body. Experience an innovative combination of advanced technologies, including the fuel injection system and a new engine for instant acceleration and maximized productivity throughout the workday. Furthermore, the user experience is refined with an easy starting procedure and low vibrations, reducing strain on your body.
Features
Features
Specifications
Specifications
Compare specifications and features with similar Husqvarna products.
Compare18" X-Tough RSN 3/8" C85 (US/CA) 970 71 15‑02 | 20" X-Tough RSN 3/8" C85 970 71 15‑03 | 24" X-Tough RSN 3/8" C85 970 71 15‑04 | 28" X-Tough RSN 3/8" C85 970 71 15‑05 | 24" US X-Tough Light RSN C85 970 71 15‑12 | 28" US X-Tough Light RSN C85 970 71 15‑13 | |
|---|---|---|---|---|---|---|
Engine | ||||||
Power output1 | 5.4 hp | 5.4 hp | 5.4 hp | 5.4 hp | 5.4 hp | 5.4 hp |
Cylinder displacement | 62.4 cm³ | 62.4 cm³ | 62.4 cm³ | 62.4 cm³ | 62.4 cm³ | 62.4 cm³ |
Torque, max. | 3.9 Nm | 3.9 Nm | 3.9 Nm | 3.9 Nm | 3.9 Nm | 3.9 Nm |
Torque, max. at rpm | 8,400 rpm | 8,400 rpm | 8,400 rpm | 8,400 rpm | 8,400 rpm | 8,400 rpm |
Chain speed at max power | 69.9 fts | 69.9 fts | 69.9 fts | 69.9 fts | 69.9 fts | 69.9 fts |
Clutch engagement speed (±120) | 4,200 rpm | 4,200 rpm | 4,200 rpm | 4,200 rpm | 4,200 rpm | 4,200 rpm |
Electrode gap | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in | 0.02 in |
Idling speed | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm | 2,800 rpm |
Ignition module air gap | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in | 0.01 in |
Maximum power speed | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm | 10,200 rpm |
Oil pump type | Adjustable flow | Adjustable flow | Adjustable flow | Adjustable flow | Adjustable flow | Adjustable flow |
Spark Plug | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H | NGK CMR6H |
18" X-Tough RSN 3/8" C85 (US/CA) 970 71 15‑02 | 20" X-Tough RSN 3/8" C85 970 71 15‑03 | 24" X-Tough RSN 3/8" C85 970 71 15‑04 | 28" X-Tough RSN 3/8" C85 970 71 15‑05 | 24" US X-Tough Light RSN C85 970 71 15‑12 | 28" US X-Tough Light RSN C85 970 71 15‑13 | |
|---|---|---|---|---|---|---|
Equipment | ||||||
Recommended bar length, min | 15 in | 15 in | 15 in | 15 in | 15 in | 15 in |
Pitch | 3/8" | 3/8" | 3/8" | 3/8" | 3/8" | 3/8" |
Recommended bar length, max | 28 in | 28 in | 28 in | 28 in | 28 in | 28 in |
Chain type | C85 | C85 | C85 | C85 | C85 | C85 |
Bar length | 45 cm | 50 cm | 60 cm | 70 cm | 60 cm | 70 cm |
Bar length (inch) | 18 in | 20 in | 24 in | 28 in | 24 in | 28 in |
Sprocket type | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 | Rim 7 |
Gauge | 1.5 mm | 1.5 mm | 1.5 mm | 1.5 mm | 1.5 mm | 1.5 mm |
18" X-Tough RSN 3/8" C85 (US/CA) 970 71 15‑02 | 20" X-Tough RSN 3/8" C85 970 71 15‑03 | 24" X-Tough RSN 3/8" C85 970 71 15‑04 | 28" X-Tough RSN 3/8" C85 970 71 15‑05 | 24" US X-Tough Light RSN C85 970 71 15‑12 | 28" US X-Tough Light RSN C85 970 71 15‑13 | |
|---|---|---|---|---|---|---|
Dimensions | ||||||
Weight (excl. cutting equipment) | 12.8 lbs | 12.8 lbs | 12.8 lbs | 12.8 lbs | 12.8 lbs | 12.8 lbs |
18" X-Tough RSN 3/8" C85 (US/CA) 970 71 15‑02 | 20" X-Tough RSN 3/8" C85 970 71 15‑03 | 24" X-Tough RSN 3/8" C85 970 71 15‑04 | 28" X-Tough RSN 3/8" C85 970 71 15‑05 | 24" US X-Tough Light RSN C85 970 71 15‑12 | 28" US X-Tough Light RSN C85 970 71 15‑13 | |
|---|---|---|---|---|---|---|
Sound and noise | ||||||
Sound pressure level at operators ear (LpA) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) | 106 dB(A) |
Sound power level, guaranteed (LWA) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) |
Sound power level, measured | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) | 117 dB(A) |
18" X-Tough RSN 3/8" C85 (US/CA) 970 71 15‑02 | 20" X-Tough RSN 3/8" C85 970 71 15‑03 | 24" X-Tough RSN 3/8" C85 970 71 15‑04 | 28" X-Tough RSN 3/8" C85 970 71 15‑05 | 24" US X-Tough Light RSN C85 970 71 15‑12 | 28" US X-Tough Light RSN C85 970 71 15‑13 | |
|---|---|---|---|---|---|---|
Vibration | ||||||
Equivalent vibration level (ahv, eq) rear handle | 3 m/s² | 3 m/s² | 3 m/s² | 3 m/s² | 3 m/s² | 3 m/s² |
Equivalent vibration level (ahv, eq) front handle | 3.3 m/s² | 3.3 m/s² | 3.3 m/s² | 3.3 m/s² | 3.3 m/s² | 3.3 m/s² |
18" X-Tough RSN 3/8" C85 (US/CA) 970 71 15‑02 | 20" X-Tough RSN 3/8" C85 970 71 15‑03 | 24" X-Tough RSN 3/8" C85 970 71 15‑04 | 28" X-Tough RSN 3/8" C85 970 71 15‑05 | 24" US X-Tough Light RSN C85 970 71 15‑12 | 28" US X-Tough Light RSN C85 970 71 15‑13 | |
|---|---|---|---|---|---|---|
Lubricant | ||||||
Oil tank volume | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint | 0.68 US pint |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 | Husqvarna 2 stroke or equiv. at 50:1 |
18" X-Tough RSN 3/8" C85 (US/CA) 970 71 15‑02 | 20" X-Tough RSN 3/8" C85 970 71 15‑03 | 24" X-Tough RSN 3/8" C85 970 71 15‑04 | 28" X-Tough RSN 3/8" C85 970 71 15‑05 | 24" US X-Tough Light RSN C85 970 71 15‑12 | 28" US X-Tough Light RSN C85 970 71 15‑13 | |
|---|---|---|---|---|---|---|
Emission | ||||||
Exhaust emissions (CO₂ EU V)2 | 762 g/kWh | 762 g/kWh | 762 g/kWh | 762 g/kWh | 762 g/kWh | 762 g/kWh |
Reviews
Reviews
Services
Services
Owner support
Owner support
Manuals, handbooks, spare parts, guides, and related information for 564 XP® Fuel Injected can be found in the product support.
Product support for 564 XP® Fuel InjectedDisclaimer:
- 1Power output: Petrol products - Net power rating as per ISO 7293, Battery products measured comparable to petrol products
- 2Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
