Commercial Ride-On Front Mowers


Power/fuel type
155 cm
Cutting width, max
132 cm
Cutting width, min
What's included
HUSQVARNA P 525DX - 967 98 53‑01


  • Steering knob

Not included

  • Cutting deck

P 525DX

High-capacity diesel-powered front mower offering unbeatable manoeuvrability and productivity in complex and narrow environments as well as in larger-sized areas. The commercial graded transmission gives uncompromised traction and slope stability. The machine's compact size and high transport speed makes it suitable both for stationary and mobile application for municipalities, contractors, housing agencies etc. Thanks to the front-mounted cutting deck the operator has perfect overview of the working area. This means optimised trimming ability as well as accessibility under benches, bushes etc. Long-life components for solid durability and less downtime. Attachments such as utility bucket, broom, folding plough and cabin give increased productivity all-year round. Husqvarna P 525DX is delivered deckless and can be fitted with 132 and 155 cm Combi cutting decks.
Compare specifications and features with similar Husqvarna products.

P 525DX 2021-

Art no: 967 98 53‑01

P 525DX 2021-
Art no: 967 98 53‑01
Power/fuel typeDiesel
Net power at preset rpm Energy1
17,8 kW
Net power at preset rpm3 000 rpm
Motor/engine manufacturerKubota
Engine nameD1105
Cylinder displacement1 123 cm³
Engine coolingLiquid
Engine lubrication typePressure with Oilfilter
Oil filterYes
Exhaust emissions (CO₂ EU V)2
1 018 g/kWh
Battery capacity62 Ah
Battery typeLead-Acid
Battery pack weight14 kg
Battery manufacturerExide
Cutting deck
Uncut circle58 cm
Cutting width, min132 cm
Cutting width, max155 cm
Cutting height min30 mm
Cutting height max112 mm
Blade engagementElectric clutch
Tyre dimensions, front20x10-10
Tyre dimensions, rear20x10-10
Wheelbase106 cm
Ground clearance140 mm
Base machine, length207,8 cm
Base machine, width115,3 cm
Base machine, height133 cm
Gross weight towed3
350 kg
Weight (excl. cutting equipment)684 kg
Drive system
PTO (Power Take Off)Shaft drive
Transmission typeHydrostatic
Transmission manufacturer, rearKanzaki
Drive methodDual pedal-operation
Speed forward max19 km/h
Speed reverse max9,3 mph
Speed reverse max15 km/h
Transmission manufacturer, frontKanzaki
Transmission model, frontKTM 23LC
Transmission model, rearKTM 23SC
Seat suspensionYes
Seat typeFull suspension, arm rests
Hour meter typeDigital
Seat materialVinyl
Seat back heightHigh
Foldable seatYes
Steering wheel typeProfessional
Parking brake, typeDisc
Vibration level steering wheel1,7 m/s²
Vibration level seat0,7 m/s²
Sound and noise
Sound pressure level at operators ear91 dB(A)
Sound power level, guaranteed (LWA)105 dB(A)
Sound power level, measured104 dB(A)
Owner support
Manuals, handbooks, spare parts, guides, and related information for P 525DX can be found in the product support.
Product support for P 525DX
  • 1Net power at preset rpm Energy: Net power rating as per SAE J1349, at specified RPM as specified by the engine manufacturer
  • 2Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
  • 3Gross weight towed: For 2-wheel drive machines, towing of trailer is only allowed in dry conditions and on flat surfaces. Be aware that towing of trailer may shorten the life time of the Rider's transmission.
