Brushcutters
Parts, manuals and support for 535RXT
All the support you need for 535RXT. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 535RXT product pageChoose article number
To show you the right support, choose an article number from this list.
Where to find my article numberSupport content
Manuals & Documents
(11)
Manuals & Documents
(11)
Showing the latest version of manual and documents for 535RXT. For earlier versions, see link below to search all manuals & documents..
Troubleshooting & help
(10)
Troubleshooting & help
(10)
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Cylinder displacement | 34.6 cm³ |
Output shaft power | 1.4 kW |
Fuel tank volume | 0.6 l |
Fuel Consumption | 475 g/kWh |
Maximum power speed | 8,400 rpm |
Idling speed | 2,900 rpm |
Maximum rpm output shaft | 8,220 rpm |
Electrode gap | 0.5 mm |
Clutch engagement speed (±120) | 3,600 rpm |
Torque, max. | 1.9 Nm |
Torque, max. at rpm | 6,600 rpm |
Spark Plug | Champion RCJ6Y |
| Capacity | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Cutting width | 47 cm |
| Equipment | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Grass blade | Multi 300-3 |
Harness | Balance X |
Saw blade | Not included |
Trimmer head | T35 M12 |
Handle type | Bullhorn |
| Dimensions | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Tube diameter | 28 mm |
Weight (excl. cutting equipment) | 6.7 kg |
Tube length | 1,483 mm |
| Lubricant | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Lubricant type (bevel gear) | Mineral grease |
| Emission | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Exhaust emissions (CO₂ EU V) | 862 g/kWh |
Exhaust emissions (HC average) EU | 40.51 g/kWh |
Exhaust emissions (HC average) CARB | 29.31 g/kWh |
Exhaust emissions (CO average) EU | 418.31 g/kWh |
Exhaust emissions (CO average) EPA | 243.69 g/kWh |
Exhaust emissions (NOx average) EU | 0.46 g/kWh |
Exhaust emissions (NOx average) EPA | 1.09 g/kWh |
| Transmission | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Gear ratio | 1.4 |
Drive gear angle | 35 ° |
| Vibration | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Equivalent vibration level (ahv, eq) left handle | 2.4 m/s² |
Equivalent vibration level (ahv, eq) right handle | 3.1 m/s² |
| Sound and noise | T35 + Multi 300-3 (1"), All ex US50 Art no: 966 62 89‑01 |
|---|---|
Sound pressure level at operators ear (LpA) | 96 dB(A) |
Sound power level, guaranteed (LWA) | 114 dB(A) |
