Brushcutters
Parts, manuals and support for 525RXT Mark II
All the support you need for 525RXT Mark II. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 525RXT Mark II product pageChoose article number
To show you the right support, choose an article number from this list.
Where to find my article numberSupport content
Manuals & Documents
(1)
Manuals & Documents
(1)
Showing the latest version of manual and documents for 525RXT Mark II. For earlier versions, see link below to search all manuals & documents..
Troubleshooting & help
(10)
Troubleshooting & help
(10)
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Cylinder displacement | 25.4 cm³ |
Output shaft power | 1 kW |
Fuel tank volume | 0.65 l |
Fuel Consumption | 600 g/kWh |
Maximum power speed | 8,500 rpm |
Idling speed | 3,000 rpm |
Maximum rpm output shaft | 8,200 rpm |
Electrode gap | 0.55 mm |
Clutch engagement speed (±120) | 4,000 rpm |
Torque, max. | 1.2 Nm |
Torque, max. at rpm | 6,000 rpm |
Spark Plug | Husqvarna HQT-2 |
| Capacity | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Cutting width | 45 cm |
| Equipment | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Grass blade | Grass 255-4 |
Harness | Balance 55 |
Saw blade | Not included |
Trimmer head | T35 M10 |
Handle type | Bike Handle |
| Dimensions | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Tube diameter | 24 mm |
Weight (excl. cutting equipment) | 5.8 kg |
Tube length | 1,483 mm |
| Lubricant | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Lubricant type (bevel gear) | Mineral grease |
| Emission | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Exhaust emissions (CO₂ EU V) | 1,141 g/kWh |
Exhaust emissions (HC average) EU | 29.55 g/kWh |
Exhaust emissions (CO average) EU | 337.1 g/kWh |
Exhaust emissions (CO average) EPA | 206.73 g/kWh |
Exhaust emissions (NOx average) EU | 0.31 g/kWh |
| Transmission | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Gear ratio | 13 |
Drive gear angle | 30 ° |
| Vibration | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Equivalent vibration level (ahv, eq) left handle | 2 m/s² |
Equivalent vibration level (ahv, eq) right handle | 2.5 m/s² |
| Sound and noise | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Sound pressure level at operators ear (LpA) | 96 dB(A) |
| Control | All ex US, T35 + Grass 255-4 (1") Art no: 970 44 67‑01 |
|---|---|
Connectivity | Husqvarna Connectivity Device |
