Pole Saws
Parts, manuals and support for 530iP4 (tool only)
All the support you need for 530iP4 (tool only). Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 530iP4 (tool only) product pageChoose your SKU
For more product support please choose your SKU below.
Spare parts
Choose the part you wish to repair
ACCESSORIES
Name
SKU
Support content
Manuals & Documents
(5)
Manuals & Documents
(5)
Showing the latest version of manual and documents for 530iP4 (tool only). For earlier versions, see link below to search all manuals & documents..
Operator's Manual
Published: 2025-06-133.01 MB,EN, FR, ESIllustrated Part List
Published: 2024-04-29215 kB,FR
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Oil tank volume | 0.15 l |
Motor type | BLDC (brushless) |
| Capacity | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Chain speed at max power | 20 m/s |
| Dimensions | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Weight (excl. cutting equipment) | 3.4 kg |
Weight (excl. battery and cutting equipment) | 3.4 kg |
Full length, including cutting equipment | 240 cm |
| Equipment | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Pitch | 3/8" |
Recommended bar length, max | 30 cm |
Recommended bar length, min | 25 cm |
Bar length (inch) | 10 in |
Nose type | Sprocket nose |
Chain type | H37 |
Battery | Not included |
Battery charger | Not included |
Harness | Single harness |
| Battery | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Battery Chemistry | Li-Ion |
Battery voltage | 36 V |
Number of batteries included | 0 |
| Vibration | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Equivalent vibration level (ahv, eq) rear handle | 1.1 m/s² |
| Sound and noise | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Sound pressure level at operators ear (LpA) | 88 dB(A) |
Sound power level, guaranteed (LWA) | 98 dB(A) |
| Control | Fixed pole saw 10" 3/8" US/CA, No Battery/Charger SKU: 967 88 46‑11 |
|---|---|
Connectivity | Not applicable |
