Ride-On Front Mowers
Parts, manuals and support for R 418Ts AWD
All the support you need for R 418Ts AWD. Manuals, spare parts, guides, how-to’s, and more.
Discontinued
See all Ride-On Front Mowers for saleChoose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
CHASSIS REAR
Article
Art. number
Support content
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Cutting deck | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Uncut circle | 50 cm |
Cutting width, min | 94 cm |
Cutting width, max | 112 cm |
Cutting height min | 25 mm |
Cutting height max | 75 mm |
Blade engagement | Automatic |
| Engine | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Power/fuel type | Petrol |
Net power at preset rpm Energy | 10,6 kW |
Engine brand | Kawasaki |
Motor/engine manufacturer | Kawasaki |
Engine name | FS Series V-Twin |
Cylinder displacement | 603 cm³ |
Cylinders | 2 |
Engine cooling | Air |
Engine lubrication type | Full pressure |
Oil filter | Yes |
| Dimensions | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Tyre dimensions, front | 165/60-8 |
Tyre dimensions, rear | 165/60-8 |
Wheelbase | 87 cm |
Ground clearance | 75 mm |
Base machine, length | 202 cm |
Base machine, width | 90 cm |
Base machine, height | 113 cm |
Gross weight towed | 150 kg |
| Vibration | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Vibration level steering wheel | 2,6 m/s² |
Vibration level seat | 0,7 m/s² |
| Drive system | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Transmission type | Hydrostatic |
Transmission manufacturer, rear | Kanzaki |
Drive method | Dual pedal-operation |
Speed forward max | 11 km/h |
Speed reverse max | 5,6 mph |
Speed reverse max | 9 km/h |
Transmission manufacturer, front | Kanzaki |
Transmission model, front | KTM10S |
Transmission model, rear | K664 |
| Battery | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Battery capacity | 24 Ah |
Battery Chemistry | Lead-Acid |
Battery Weight | 7 kg |
Battery brand | Global |
| Equipment | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Seat suspension | Yes |
Seat type | Professional |
Hour meter type | Digital with pre-programmed service intervals |
Seat material | Vinyl |
Seat back height | High |
Foldable seat | Yes |
Steering wheel type | Comfort |
Parking brake, type | Disc |
| Sound and noise | R 418Ts AWD (2013-) Art no: 967 15 85‑01 |
|---|---|
Sound pressure level at operators ear (LpA) | 83 dB(A) |
Sound power level, guaranteed (LWA) | 98 dB(A) |
Sound power level, measured | 97 dB(A) |
