Power Cutters
Parts, manuals and support for K 970 Ring
All the support you need for K 970 Ring. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to K 970 Ring product pageChoose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
CRANKSHAFT
Article
Art. number
Support content
Manuals & Documents
(1)
Manuals & Documents
(1)
Showing the latest version of manual and documents for K 970 Ring. For earlier versions, see link below to search all manuals & documents..
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | POWER CUTTER K 970 Ring 370 mm Art no: 967 27 23‑01 |
|---|---|
Output power | 4,8 kW |
Cylinder displacement | 93,6 cm³ |
Electrode gap | 0,5 mm |
Cylinders | 1 |
Number of strokes | 2-stroke engine |
| Cutting System | POWER CUTTER K 970 Ring 370 mm Art no: 967 27 23‑01 |
|---|---|
Blade diameter, max | 370 mm |
Blade thickness, max | 5,6 mm |
Peripheral speed, max | 55 m/s |
| Dimensions | POWER CUTTER K 970 Ring 370 mm Art no: 967 27 23‑01 |
|---|---|
Product size length | 784,6 mm |
Product size width | 224,2 mm |
Product size height | 430,7 mm |
Weight (complete product w/o side packed articles) | 13,8 kg |
| Cutting deck | POWER CUTTER K 970 Ring 370 mm Art no: 967 27 23‑01 |
|---|---|
Cutting depth, max | 270 mm |
| Sound and noise | POWER CUTTER K 970 Ring 370 mm Art no: 967 27 23‑01 |
|---|---|
Sound power level, guaranteed (LWA) | 115 dB(A) |
Sound pressure level at operators ear (LpA) | 104 dB(A) |
| Emission | POWER CUTTER K 970 Ring 370 mm Art no: 967 27 23‑01 |
|---|---|
Exhaust emissions (CO₂ EU V) | 736 g/kWh |
| Vibration | POWER CUTTER K 970 Ring 370 mm Art no: 967 27 23‑01 |
|---|---|
Vibrations left/front handle | 2,7 m/s² |
Vibrations right/rear handle | 3,4 m/s² |
