Chainsaws
Parts, manuals and support for 572 XP®
All the support you need for 572 XP®. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 572 XP® product pageChoose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
CYLINDER PISTON
Article
Art. number
Support content
Manuals & Documents
(15)
Manuals & Documents
(15)
Showing the latest version of manual and documents for 572 XP®. For earlier versions, see link below to search all manuals & documents..
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | 18" SN 3/8" 1,5 mm C85 Art no: 966 73 31‑18 |
|---|---|
Chain speed at max power | 22 m/s |
Cylinder displacement | 70,6 cm³ |
Output shaft power | 4,3 kW |
| Dimensions | 18" SN 3/8" 1,5 mm C85 Art no: 966 73 31‑18 |
|---|---|
Weight (excl. cutting equipment) | 6,6 kg |
| Equipment | 18" SN 3/8" 1,5 mm C85 Art no: 966 73 31‑18 |
|---|---|
Recommended bar length, min | 38 cm |
Recommended bar length, max | 70 cm |
Pitch | 3/8" |
Chain type | C85 |
Bar length | 45 cm |
Bar length (inch) | 18 in |
| Emission | 18" SN 3/8" 1,5 mm C85 Art no: 966 73 31‑18 |
|---|---|
Exhaust emissions (CO₂ EU V) | 841 g/kWh |
| Vibration | 18" SN 3/8" 1,5 mm C85 Art no: 966 73 31‑18 |
|---|---|
Equivalent vibration level (ahv, eq) front handle | 5 m/s² |
Equivalent vibration level (ahv, eq) rear handle | 4,1 m/s² |
| Sound and noise | 18" SN 3/8" 1,5 mm C85 Art no: 966 73 31‑18 |
|---|---|
Sound pressure level at operators ear (LpA) | 107 dB(A) |
Sound power level, guaranteed (LWA) | 120 dB(A) |
