Chainsaws
Parts, manuals and support for 455
All the support you need for 455. Manuals, spare parts, guides, how-to’s, and more.
Discontinued
See all Chainsaws for saleChoose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
CRANKSHAFT
Article
Art. number
Support content
Manuals & Documents
(5)
Manuals & Documents
(5)
Showing the latest version of manual and documents for 455. For earlier versions, see link below to search all manuals & documents..
Illustrated Part List
Published: 2022/02/1453.8 kB,ENOperator's Manual
Published: 2012/06/018.73 MB,EN
Accessories
(29)
Accessories
(29)
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
15" - .325" - SN- H25 CE, AS 966 76 77‑15 | |
|---|---|
Engine | |
Chain speed at max power | 20 m/s |
Cylinder displacement | 55,5 cm³ |
Output shaft power | 2,6 kW |
15" - .325" - SN- H25 CE, AS 966 76 77‑15 | |
|---|---|
Dimensions | |
Weight (excl. cutting equipment) | 5,9 kg |
15" - .325" - SN- H25 CE, AS 966 76 77‑15 | |
|---|---|
Equipment | |
Recommended bar length, min | 38 cm |
Recommended bar length, max | 60 cm |
Pitch | .325" |
Chain type | H25 |
Bar length | 38 cm |
Bar length (inch) | 15 in |
15" - .325" - SN- H25 CE, AS 966 76 77‑15 | |
|---|---|
Emission | |
Exhaust emissions (CO₂ EU V) | 883 g/kWh |
15" - .325" - SN- H25 CE, AS 966 76 77‑15 | |
|---|---|
Vibration | |
Equivalent vibration level (ahv, eq) front handle | 3,8 m/s² |
Equivalent vibration level (ahv, eq) rear handle | 6,9 m/s² |
15" - .325" - SN- H25 CE, AS 966 76 77‑15 | |
|---|---|
Sound and noise | |
Sound pressure level at operators ear (LpA) | 104 dB(A) |
Sound power level, guaranteed (LWA) | 114 dB(A) |
