Brushcutters
Parts, manuals and support for 331R
All the support you need for 331R. Manuals, spare parts, guides, how-to’s, and more.
Currently available
Go to 331R product pageChoose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
TUBE
Article
Art. number
Support content
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Engine | |
Cylinder displacement | 32,6 cm³ |
Output shaft power | 1 kW |
Fuel tank volume | 1,1 l |
Fuel Consumption | 550 g/kWh |
Maximum power speed | 7 000 rpm |
Idling speed | 3 000 rpm |
Maximum rpm output shaft | 7 800 rpm |
Electrode gap | 0,6 mm |
Clutch engagement speed (±120) | 4 880 rpm |
Torque, max. | 1,3 Nm |
Torque, max. at rpm | 6 000 rpm |
Spark Plug | NGK BPM7A |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Capacity | |
Cutting width | 43 cm |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Equipment | |
Grass blade | Multi 330-2 |
Harness | Single harness |
Saw blade | Not included |
Trimmer head | Not included |
Handle type | Bullhorn |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Dimensions | |
Tube diameter | 28 mm |
Weight (excl. cutting equipment) | 7,2 kg |
Tube length | 1 495 mm |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Lubricant | |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Lubricant type (bevel gear) | Mineral grease |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Transmission | |
Gear ratio | 0,74 |
Drive gear angle | 30 ° |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Vibration | |
Equivalent vibration level (ahv, eq) left handle | 6,1 m/s² |
Equivalent vibration level (ahv, eq) right handle | 6,2 m/s² |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Sound and noise | |
Sound pressure level at operators ear (LpA) | 97 dB(A) |
Sound power level, guaranteed (LWA) | 108 dB(A) |
Bullhorn Brushcutter,SouthEast ASIA,ZA,LA ex BR,PY 967 86 65‑02 | |
|---|---|
Control | |
Connectivity | Not applicable |
