Residential Robotic Lawn Mowers

Husqvarna Automower® 420 iQ












4,000 m²
Area capacity
Physical wire, Virtual wire
Boundary type
Automower® Connect
App controlled

Husqvarna Automower® 420 iQ - 970 72 75‑06
Included
  • Charging station
    Yes
  • Extra blades
    6 pcs
  • Power supply unit
    Yes
  • Low voltage cable
    10 m
  • Stakes
    100 pcs
  • EPOS® Plug-in
    Yes
  • EPOS® Reference station
    Yes
Not included
  • Loop wire

Automower® 420 iQ

Break free from the chore of mowing with Automower® iQ Series robotic mowers. Our Exact Positioning Operating System (EPOS®) uses patented technology, communicating with multiple satellites and the national cellular network to provide centimeter-accurate location data to your mower. Redesigned with an optimized bumper and larger wheels, these mowers are built to tackle any challenges in your lawn, including surface transitions and slopes. And with total control from the Automower® Connect app, you can easily and instantly adjust your mower settings, including custom stay-out zones, mowing schedules, cut height, and more.

*Source: Euromonitor International Limited; per Robotic Lawn Mowers category definition; Home and Garden 2025ed; retail value sales in RSP, 2024 data.

Features

Specifications

Compare specifications and features with similar Husqvarna products.
Compare
AM420 iQ NZ Robotic Lawn Mower
970 72 75‑06
Capacity

Area capacity

4,000 m²

Area capacity - irregular

2,000 m²

Area capacity - systematic

4,000 m²

Boundary type

Physical wire, Virtual wire

Maximum slope performance at boundary

15 %

Maximum slope performance inside installation

45 %

Max active time

24 h

Follow guide

3

Charging system

Automatic
AM420 iQ NZ Robotic Lawn Mower
970 72 75‑06
Overall dimensions

Weight (complete product w/o side packed articles)

17.2 kg

Product size length

75 cm

Product size width

54 cm

Product size height

28 cm
AM420 iQ NZ Robotic Lawn Mower
970 72 75‑06
Product data

Colour

Grey

Sound level perceived

62 dB(A)

Protection Index (IP Code)

IPX5

Battery chemistry

Li-Ion

Battery capacity

5 Ah

Charging current

4.2 A

Typical mow time on one charge

84 min

Typical charging time

54 min

Mean energy consumption per month at maximum use

8.7 kWh
AM420 iQ NZ Robotic Lawn Mower
970 72 75‑06
Cutting System

Cutting system

3 pivoting razor blades

Cutting height max

100 mm

Cutting height min

25 mm

Cutting width

24 cm

Cutting height adjustment

Electric

Skid plate

Yes

Dual cutting direction

Yes
AM420 iQ NZ Robotic Lawn Mower
970 72 75‑06
Control

User Interface

Jogwheel, display and status LED:s/App

Display

Color Display TFT 2,8” QVGA

Connectivity

Cellular, Wi-Fi, Bluetooth®

App controlled

Automower® Connect

Smart Home integration

Yes

Firmware Update

FOTA
AM420 iQ NZ Robotic Lawn Mower
970 72 75‑06
Safety

GPS Theft tracking

Yes

GeoFence

Yes

PIN code

Yes

Alarm

Yes

Lift sensor

Yes

Tilt sensor

Yes

Object detection

Radar

Reviews

Services

Owner support

Manuals, handbooks, spare parts, guides, and related information for Automower® 420 iQ can be found in the product support.
