Power Cutters
Parts, manuals and support for K 1270 II
All the support you need for K 1270 II. Manuals, spare parts, guides, how-to’s, and more.
Choose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
BLADE GUARD
Article
Art. number
Support content
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Engine | POWER CUTTER K 1270 16" | 1" / 20mm Art no: 967 97 88‑01 |
|---|---|
Output power | 5.8 kW |
Cylinder displacement | 118.8 cm³ |
Electrode gap | 0.5 mm |
Cylinders | 1 |
Number of strokes | 2-stroke engine |
| Cutting System | POWER CUTTER K 1270 16" | 1" / 20mm Art no: 967 97 88‑01 |
|---|---|
Blade diameter, max | 400 mm |
Arbor diameter | 25.4/20 mm |
Blade thickness, max | 5 mm |
Peripheral speed, max | 90 m/s |
| Dimensions | POWER CUTTER K 1270 16" | 1" / 20mm Art no: 967 97 88‑01 |
|---|---|
Product size length | 743 mm |
Product size width | 241 mm |
Product size height | 473 mm |
Weight (complete product w/o side packed articles) | 14.2 kg |
| Cutting deck | POWER CUTTER K 1270 16" | 1" / 20mm Art no: 967 97 88‑01 |
|---|---|
Cutting depth, max | 145 mm |
| Sound and noise | POWER CUTTER K 1270 16" | 1" / 20mm Art no: 967 97 88‑01 |
|---|---|
Sound power level, guaranteed (LWA) | 117 dB(A) |
Sound pressure level at operators ear (LpA) | 104 dB(A) |
| Emission | POWER CUTTER K 1270 16" | 1" / 20mm Art no: 967 97 88‑01 |
|---|---|
Exhaust emissions (CO₂ EU V) | 726 g/kWh |
| Vibration | POWER CUTTER K 1270 16" | 1" / 20mm Art no: 967 97 88‑01 |
|---|---|
Vibrations left/front handle | 3.9 m/s² |
Vibrations right/rear handle | 4 m/s² |
