Ride-On Front Mowers
Parts, manuals and support for R 213C
All the support you need for R 213C. Manuals, spare parts, guides, how-to’s, and more.
Discontinued
See all Ride-On Front Mowers for saleChoose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
CHASSIS / FRAME
Article
Art. number
Support content
Manuals & Documents
(5)
Manuals & Documents
(5)
Showing the latest version of manual and documents for R 213C. For earlier versions, see link below to search all manuals & documents..
Accessories
(2)
Accessories
(2)
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
| Cutting deck | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Uncut circle | 30 cm |
Cutting width, min | 94 cm |
Cutting width, max | 94 cm |
Cutting height min | 25 mm |
Cutting height max | 75 mm |
Blade engagement | Automatic |
| Engine | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Power/fuel type | Petrol |
Net power at preset rpm Energy | 6.6 kW |
Engine brand | Briggs & Stratton |
Motor/engine manufacturer | Briggs & Stratton |
Engine name | Intek |
Cylinder displacement | 344 cm³ |
Cylinders | 1 |
Engine cooling | Air |
Engine lubrication type | Pressure |
Oil filter | Yes |
| Dimensions | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Tyre dimensions, front | 170/60-8 |
Tyre dimensions, rear | 170/60-8 |
Wheelbase | 88.7 cm |
Ground clearance | 105 mm |
Base machine, length | 223 cm |
Base machine, width | 100 cm |
Base machine, height | 107 cm |
Gross weight towed | 110 kg |
| Vibration | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Vibration level steering wheel | 2.5 m/s² |
Vibration level seat | 0.7 m/s² |
| Drive system | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Transmission type | Hydrostatic |
Drive method | Dual pedal-operation |
Speed forward max | 9 km/h |
Speed reverse max | 5.6 mph |
Speed reverse max | 9 km/h |
| Battery | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Battery capacity | 24 Ah |
Battery Chemistry | Lead-Acid |
Battery Weight | 7.2 kg |
Battery brand | Global |
| Equipment | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Seat suspension | Yes |
Hour meter type | Digital |
Seat material | PU |
Seat back height | Medium |
Foldable seat | Yes |
Steering wheel type | Comfort |
Parking brake, type | Disc |
| Sound and noise | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Sound pressure level at operators ear (LpA) | 84 dB(A) |
Sound power level, guaranteed (LWA) | 100 dB(A) |
Sound power level, measured | 98 dB(A) |
| Emission | R 213C 2019- Art no: 967 84 66‑01 |
|---|---|
Exhaust emissions (CO₂ EU V) | 882 g/kWh |
